The touchless IR Thermal Scanner needs to be installed at the entrance or outside the home door or at the entrance of societies, offices, medical facilities, schools, etc. The Scanner uses an IR thermal sensor to detect the body temperature of a person. When a person walks in front of the scanner, the scanner need not be touched by the person and he/she is automatically detected using the infrared thermal sensing if he/she is standing within 20 cm of the scanner using our in-built distance sensor. If the detected body temperature is within the normal body temperature of 33°C-37°C,then the buzzer beeps once. If it’s between 37°C-41°C it detects that the person is sick and beeps the buzzer for 3 secs as well as actuates the output relay 3 times which could be connected to a hooter/doorbell/automated door system, etc, alarming the persons inside of a sick person outside. If the temperature is below 33°C or above 41°C then the scanner output remains inactive. The installation does not need any civil work or rewiring. Fits in the existing space on a wall and needs to be plugged in a regular 110-230V AC socket.The main USP’s of the product are as follows:

• No operator needed to operate the scanner. Its wall-mount and Touchless – unlike the handheld thermal scanners. This removes the risk of the operator contracting the disease from an infected person and then re-transmitting to all the people getting scanned subsequently
• Plug and Play – Just Stick it on the wall at comfortable height and plug into a 110-240VAC power socket to power up
• Completely Battery-less – Avoids having to change batteries and run into additional costs and incorrect readings due to low battery. Works continuously
• Has Relay Output – Can be used to control automated doors to allow/disallow people based on their health condition
• In-built Distance Sensor – to avoid incorrect measuring distance and incorrect reading which is a possibility with a handheld scanner
• Results under 1 sec- For faster access control

Application Areas:

• • Government Buildings
  • Office Buildings
  • Private/Public Hospitals
  • Society Buildings
  • Restaurants
  • Malls
  • Movie Theatres
  • Police Stations
  • Individual Homes – As its actually in the same shape of a doorbell (All homes can replace their
    doorbell switch with the scanner and connect relay output to the home doorbell)
  • Any establishments which have people going in and out

Once the government decides to roll back the lock down the rules may mandate establishments to have the thermal scanning for all persons entering their buildings/offices. This we believe is a product fit for the same requirement since it’s completely touchless

Detailed working

• When no person is standing in front of the detector, the detector blue indicator LED stays on
• When a person with body temperature between 33°C-37°C stands within 20 cm of the detector the blue indication LED starts blinking and the bell rings once
• When a Person with body temperature between 38°C-41°C stands within 20cm of the detector the red indication LED starts blinking and the bell rings 5 times.The detector is completely touchless and automatic
• When the person moves out from front of the detector the detector blue indicator LED again gets turned on and stays on
